Pressure Vessel, Fine-Grained Steel Plates En10028-2 and En10028-3
Pioneer in exporting & distributing Pressure Vessel, Fine-Grained Steel Plates En10028-2 and En10028-3
OurProducts: Pressure Vessel, Fine-Grained Steel Plates En10028-2 and En10028-3
We introduce ourselves as one of the leading distributor & exporter of Pressure Vessel, Fine-Grained Steel Plates En10028-2 and En10028-3 , Mumbai
Products & Materials
BS EN 10028-2 Hot Rolled Pressure Vessel Steel Plates
P235GH EN 10028-2 Hot Rolled Steel Plates - Available ex-stock P265GH EN 10028-2 Hot Rolled Steel Plates - Available ex-stock P295GH EN 10028-2 Hot Rolled Steel Plates - Available ex-stock P355GH EN 10028-2 Hot Rolled Steel Plates - Available ex-stock
BS EN 10028-3 Hot Rolled Fine Grained Steel Plates
P275NH EN 10028-3 Hot Rolled Steel Plates - Available ex-stock P275NL1 EN 10028-3 Hot Rolled Steel Plates - Available ex-stock P275NL2 EN 10028-3 Hot Rolled Steel Plates - Available ex-stock P355N EN 10028-3 Hot Rolled Steel Plates - Available ex-stock P355NH EN 10028-3 Hot Rolled Steel Plates - Available ex-stock P355NL1 EN 10028-3 Hot Rolled Steel Plates - Available ex-stock P355NL2 EN 10028-3 Hot Rolled Steel Plates - Available ex-stock P460NH EN 10028-3 Hot Rolled Steel Plates - Available ex-stock P460NL1 EN 10028-3 Hot Rolled Steel Plates - Available ex-stock P460NL2 EN 10028-3 Hot Rolled Steel Plates - Available ex-stock
Plates
PLATES OF STEELS ACCORDING TO EN 10025-2
The most commonly used structural steels having minimum yield strength min. 235 MPa and guaranteed weldability that can be used for low demanding steel structures for bridges, halls, parts of railway and motor vehicles, etc.
Designation
Min. Yield Strength ReH 2) [MPa]
Tensile Strength Rm [MPa]
Min. Elongation [%]
Min. Impact Energy KV [°C/J] - longitudinal
CEV max.1)
Dimension Table No.
Max. Thickness [mm]
Max. Thickness for option (C) [mm]
S235JR(C)
235
360-510
24
+20/27
0,35
Table 1
80 3)
30 4)
S235J0(C)
235
360-510
24
0/27
0,35
Table 1
80 3)
30 4)
S235J2(C)
235
360-510
24
-20/27
0,35
Table 1
80 3)
30 4)
S275JR(C)
275
410-560
21
+20/27
0,40
Table 1
80 3)
30 4)
S275J0(C)
275
410-560
21
0/27
0,40
Table 1
80 3)
30 4)
S275J2(C)
275
410-560
21
-20/27
0,40
Table 1
80 3)
30 4)
S355JR(C)
355
470-630
20
+20/27
0,45
Table 1
80 3)
30 4)
S355J0(C)
355
470-630
20
0/27
0,45
Table 1
80 3)
30 4)
S355J2(C)
355
470-630
20
-20/27
0,45
Table 1
80 3)
30 4)
S355K2(C)
355
470-630
20
-20/40
0,45
Table 1
80 3)
30 4)
Plates Of Fine-Grain Steels According To En 10025-3
Thermomechanical Rolled Plates Of Fine-Grain Steels According To En 10025-4
Plates Of Steels According To ASTM - A 36, A 283, A 529
Plates Of Steels According To 10025-5
Plates Made Of Steels According To ASTM
Normalized Plates Of Steels According To En 10225
Plates For Pipes According To Api 5l 1) And En 10208-2 1) ( Sweet Service )
Plates For Pipes According To Api 5l 1) And En 10208-2 1) ( Sour Service 4) )
Plates According To Individual Shipping Companies
Plates According To ASTM A 131
Thermomechanical Rolled Plates Of Steels According To En 10149-2
Normalized (Rolled) Plates Of Steels According To En 10149-3
Plates Of Steels According To En 10083-2 And En 10083-3
Plates Of Steels According To Designation A 827, A 829, A 830
Plates Of Steels For Simple Pressure Vessels According To En 10207
Plates Of Steels According To En 10028-2
Plates Of Fine-Grained Steels According To En 10028-3
Thermomechanical Rolled Plates Of Fine-Grain Steels According To En 10028-5
Plates Of Steels According To ASTM
Thermomechanical Rolled Plates Of Steels According To En 10225
Plates Made Of Steels According To Api 2h
Plates Of Steels According To En 10084
Plates Of Steels According To En 10085
Plates Of Steels According To En Iso 4957
Plates Of Steels For Simple Pressure Vessels According To En 10207
Plates Of Steels According To En 10028-2
Plates Of Fine-Grain Steels According To En 10028-3
Thermomechanical Rolled Plates Of Fine-Grain Steels According To En 10028-5
Plates Of Steels According To ASTM/Asme
Plates Of Fine-Grain Steels According To ASTM/ASME
We are in this line from the last 25 years and supplying materials to all over the country. Most of our clients are govt.of india & public undertaking companies to defence, fertilizer, chemical, thermal power semi govt.and public sector departments.
EN 10028_2/3 Plates, best quality Pressure Vessel, Fine-Grained Steel Plates En10028-2 and En10028-3, wide variety of EN 10028_2/3 Plates, EN 10028_2/3 Plates India, EN 10028_2/3 Plates distributor Mumbai, EN 10028_2/3 Plates traders, prime quality EN 10028_2/3 Plates, Source for EN 10028_2/3 Plates, specialize in EN 10028_2/3 Plates, EN 10028_2/3 Plates with Test Certificate
