Bars & Forgings For Oil & Gas Industry
Click any of our material grades below for further detail and size availability.
| Our Grade | Equivalent Standard | AISI 4130 NACE
AISI 4140 Non-NACE
AISI 4140 NACE
AISI 4340 NACE
AISI 8630 Mod NACE
AISI 410 NACE
17-4 PH NACE
Alloy K500 NACE
Alloy 718 NACE
| AISI 4130
AISI 4140
AISI 4140
AISI 4340
AISI 8630 modified
UNS S41000
UNS S17400
UNS N05500
UNS N07718 | | AISI 4130 (NACE) | | Typical Analysis, % | C 0.28-0.33, Si 0.15-0.35, Mn 0.40-0.60, Cr 0.80-1.10
Mo 0.15-0.25, V 0.05 max, S 0.025 max, P 0.025 max | | Supplied Condition | Normalised, hardened and tempered. | | Typical Hardness | 207-235 BHN | | Stock Range | Round: 25 - 920mm
Square: 260 - 485mm
| | | AISI 4140 (Non-NACE) | | Typical Analysis, % | C 0.38-0.43, Si 0.15-0.35, Mn 0.75-1.00, Cr 0.80-1.10, Mo 0.15-0.25
S 0.025 max, P 0.025 max | | Supplied Condition | Normalised, hardened and tempered. | | Typical Hardness | 277-302 BHN | | Stock Range | Round: 36 - 690mm
| | | AISI 4140 (NACE) | | Typical Analysis, % | C 0.38-0.43, Si 0.15-0.35, Mn 0.75-1.00, Cr 0.80-1.10, Mo 0.15-0.25
Ni 0.25 max, V 0.30 max, S 0.025 max, P 0.025 max, Cu 0.35 max | | Supplied Condition | Normalised, hardened and tempered. | | Typical Hardness | 207-235 BHN | | Stock Range | Round: 50 - 450mm
| | | AISI 4340 (NACE) | | Typical Analysis, % | C 0.38-0.43, Si 0.15-0.35, Mn 0.60-0.80, Cr 0.70-0.90, Mo 0.20-0.30
Ni 1.65-2.00, S 0.040 max, P 0.035 max | | Supplied Condition | Hardened and tempered. | | Typical Hardness | 207-235 BHN | | Stock Range | Round: 16 - 400mm
| | | AISI 8630 Mod (NACE) | | Typical Analysis, % | C 0.28-0.33, Si 0.15-0.35, Mn 0.75-0.95, Cr 0.80-1.00, Mo 0.35-0.45
Ni 0.70-0.90, S 0.025 max, P 0.025 max | | Supplied Condition | Hardened and tempered. | | Typical Hardness | 217-235 BHN | | Stock Range | Round: 360 - 850mm
| | | AISI 410 Stainless (NACE) | | Typical Analysis, % | C 0.07-0.15, Si 1.00 max, Mn 1.00 max, Cr 11.50-13.50, Mo 0.50 max
Ni 0.40 max, S 0.025 max, P 1.025 max | | Supplied Condition | Hardened and double tempered. | | Typical Hardness | 207-235 BHN | | Stock Range | Round: 32 - 692mm
Square: 225 - 465mm
| | | 17-4 PH (Stainless) (NACE) | | Typical Analysis, % | C 0.07 max, Si 1.00 max, Mn 1.00 max, Cr 15.50-17.50, Ni 3.00-5.00
S 0.03 max, P 0.05.max, Cu 3.00-5.00, Cb+Ta 0.15-0.45 | | Supplied Condition | Solution annealed an double aged (2 x H1150). | | Typical Hardness | 279-311 BHN | | Stock Range | Round: 30 - 300mm
| | | Alloy K500 (NACE) | | Typical Analysis, % | C 0.25 max, Si 0.50 max, Mn 1.50 max, Ni 63.0-70.0, S 0.01 max
Al 2.30-3.15, Fe 2.00 max, Cu 27.00-33.00, Ti 0.35-0.85 | | Supplied Condition | Hot finished (worked), solution annealed and age hardened. | | Typical Hardness | 255-321 BHN | | Stock Range | Round: 32 - 45mm
| | | Alloy 718 (NACE) | | Typical Analysis, % | C 0.08 max, Si 0.35 max, Mn 0.35 max, Cr 17.00-21.00, Mo 2.80-3.30
Ni+Co 50.00-55.00 S 0.015 max, P 0.015 max, Al 0.20-0.80, Cu 0.30 max
Ti 0.65-1.15, Cb+Ta 4.75-5.50, Co 1.00 max, B 0.006 max, Fe Bal. | | Supplied Condition | Solution annealed and age hardened. | | Typical Hardness | 298-362 BHN | | Stock Range | Round: 32 - 110mm
| | We are in this line from the last 25 years and supplying materials to all over the country. Most of our clients are govt.of india & public undertaking companies to defence, fertilizer, chemical, thermal power semi govt.and public sector departments. Bars For Oil & Gas, best quality Bars For Oil & Gas, wide variety of Bars For Oil & Gas, Bars For Oil & Gas India, Bars For Oil & Gas distributor Mumbai, Bars For Oil & Gas traders, prime quality Bars For Oil & Gas, Source for Bars For Oil & Gas, specialize in Bars For Oil & Gas, Bars For Oil & Gas with Test Certificate Contact: Total Piping Solutions Mafatlal House, H.T.Parekh Marg,
